ToolkitRC M8 300W 5A 2-8S Balance Charger/ Cell Checker/ Watt Meter/ Servo Tester - White

The ToolkitRC M8 is a multi-function device, besides a 300w 15A charger, it integrated with a servo tester, cell checker, a watt meter, PWM/PPM/Sbus input testers and output generators along with a variable voltage and amperage DC output control.

  • Battery Charger
  • Cell Checker
  • Servo Tester
  • PWM,PPM.SBUS Input/output Receiver & Flight control tester
  • Viable AMp/volt DC Power supply (Required external DC input)

share


$87.00
AUD $87.00
    • Charge, discharge and balance management support LiPo, LiHV,
    • LiFe 1-8S，NiMh 1-20S，PB 1-12S battery.
    • Charger current：MAX 15A @ 300W
    • Discharge current：reccycle mode 15A @ 300W Normal: 3A @ 20W
    • Balance current: 400mA @ 2-8S
    • Lithium battery cut-off voltage can be set (TVC function)
    • Measure battery voltage, internal resistance, balance
    • ESC power meter, together with output voltage and throttle signal
    • Measure PWM / PPM / xBUS signal values, Accuracy 1ms
    • Output PWM / PPM / xBUS standard signal, Accuracy 1ms
    • Customizable 5-30V constant voltage, 1-15A constant current
    • Charge the drone battery, activate and charge.
    • Multi-language optional

    USB 2.1A@5.0V Output，for Mobile devices
    Udisk firmware upgrade (Slave device)
    Charger

    Input voltage: 7.0-30.0V @MAX 16A
    Type of battery: Lipo LiHV LiFe @1-8S
    NiMh @1-20S Pb @1-10S
    Balance current: 400mA @2-8S
    Charge power: 300W @MAX 15A
    Discharge power: 300W @MAX 15A Recycle mode
    12W @ 3A Normal mode
    USB: 2.1A @5.0V or Upgrade
    Dimensions: 98*68*35 mm
    Weight: 142g
    LCD: 2.2inch, 132*64 Pixel，black and white
    Measurement

    PWM: 880-2200us @20-400Hz
    PPM: 880-2200us*8CH @20-50Hz
    SBUS: 880-2200us*16CH @20-100Hz
    Voltage: 1.0-5.0V @1-8S
    IR: 10-500mR @1-8S
    ESC: 300W @Max 15A
    Output

    PWM: 880-2200us @20-400Hz
    PPM: 880-2200us*8CH @20-50Hz
    SBUS: 880-2200us*16CH @20-100Hz
    Power: 1.0-30.0V @1.0-15A Mode:CC+CV
    OverCurrent Cut Off time: 50ms

    • 1 x ToolkitRC M8 Muti-function charger
